Switch Fortinet FortiSwitch 248E-FPOE 48 portas Gigabit + 4 SFP 48 portas PoE+ 740W FS-248E-FPOE

FORTISWITCH FORTILINK MODE (WITH FORTIGATE)

Management and Configuration

Auto Discovery of Multiple Switches

Yes

Number of Managed Switches per FortiGate

8 to 256 Depending on FortiGate Model (Please refer to admin guide)

FortiLink Stacking (Auto Inter-Switch Links)

Yes

Software Upgrade of Switches

Yes

Centralized VLAN Configuration

Yes

Switch POE Control

Yes

Link Aggregation Configuration

Yes

Spanning Tree

Yes

LLDP/MED

Yes

IGMP Snooping

Yes (not supported on 1xxE-Series)

L3 Routing and Services

Yes (FortiGate)

Policy-Based Routing

Yes (FortiGate)

Virtual Domain

Yes (FortiGate)

Security and Visibility

802.1x Authentication (Port-based, MAC-based, MAB)

Yes

Syslog Collection

Yes

DHCP Snooping

Yes

Device Detection

Yes

MAC Black/While Listing

Yes (FortiGate)

Policy Control of Users and Devices

Yes (FortiGate)

UTM Features

Firewall

Yes (FortiGate)

IPC, AV, Application Control, Botnet

Yes (FortiGate)

High Availability

Support FortiLink FortiGate in HA Cluster

Yes

LAG support for FortiLink Connection

Yes

Active-Active Split LAG from FortiGate to FortiSwitches for Advanced Redundancy

Yes (with FS-2xx, 4xx, 5xx)

FORTISWITCH 248D

FORTISWITCH 248E-POE

FORTISWITCH 248E-FPOE

Hardware Specifications

Total Network Interfaces

48x GE RJ45 ports and

48x GE RJ45 ports and

48x GE RJ45 ports and

4x GE SFP ports

4x GE SFP ports

4x GE SFP ports

Dedicated Management 10/100 Port

1

1

1

RJ-45 Serial Console Port

1

1

1

Form Factor

1 RU Rack Mount

1 RU Rack Mount

1 RU Rack Mount

Power over Ethernet (PoE) Ports

—

24 (802.3af/802.3at)

48 (802.3af/802.3at)

PoE Power Budget

N/A

370 W

740 W

Mean Time Between Failures

> 10 years

> 10 years

> 10 years

System Specifications

Switching Capacity (Duplex)

104 Gbps

104 Gbps

104 Gbps

Packets Per Second (Duplex)

155 Mpps

155 Mpps

155 Mpps

MAC Address Storage

16 K

16 K

16 K

Network Latency

< 1µs

< 1µs

< 1µs

VLANs Supported

4 K

4 K

4 K

Link Aggregation Group Size

8

8

8

Total Link Aggregation Groups

Up to number of ports

Up to number of ports

Up to number of ports

Packet Buffers

1.5 MB

1.5 MB

1.5 MB

DRAM

512 MB

512 MB

512 MB

FLASH

128 MB

128 MB

128 MB

Dimensions

Height x Depth x Width (inches)

1.73 x 9.68 x 17.3

1.73 x 16.1 x 17.3

1.73 x 16.1 x 17.3

Height x Depth x Width (mm)

44 x 246 x 440

44 x 410 x 440

44 x 410 x 440

Weight

7.81 lbs (3.54 kg)

12.12 lbs (5.5 kg)

13.44 lbs (6.1 kg)

Environment

Power Required

100–240V AC, 50–60 Hz

100–240V AC, 50–60 Hz

100–240V AC, 50–60 Hz

Power Supply

AC built in

AC built in

AC built in

Redundant Power

—

Optional FRPS-740

Optional FRPS-740

Power Consumption (Average / Maximum)

38.66 W / 39.19 W

457.46 W / 466.47 W

842 W / 855.02 W

Heat Dissipation

134 BTU/h

177.14268 BTU/h

162.87865 BTU/h

Operating Temperature

32–122°F (0–50°C)

32–122°F (0–50°C)

32–122°F (0–50°C)

Storage Temperature

-4–158°F (-20–70°C)

-4–158°F (-20–70°C)

-4–158°F (-20–70°C)

Humidity

10–90% non-condensing

10–90% non-condensing

10–90% non-condensing
